Usage
The machince is suitable for splitting and trimming the super-sized coiled material like plastic films, i. E. Paper, cloth and all kinds of paper-plastic compound materials like laminated paper, coating paper, synthetic leathers and so on for printing and packing.
Performances and Characteristics
To adopt round blade to split, featuring in high precision and easy operation. Adjustable slitting blades;
To adopt A/B shaft to rewind independently, featuring in easy installing, dismounting and operation;
The air-expansion shafts are adopted for rewinding and unwinding, with automatic control of tension, featuring in orderly and compact rewinding of finished products;
The feeding support is of automatic hydraulic pressure lift;
With an automatic discharging device for discarded sides;
The machine adopts frequency speed control, microcomputer automatic controller, imported hydraulic pressure rectifying device, featuring in automatic counting, stop upon alarming, digital displayer for tension, etc

Model	QFJ-1100	QFJ-1300	QFJ-1600
Max. Width of unwinding roll	1100mm	1300mm	1600mm
Max. Diameter of unwinding Roll	1400mm	1400mm	1400mm
Max. Diameter of rewinding Roll	800mm	800mm	800mm
Width of rewinding Roll	20 -1100mm	20 -1300mm	20 -1600mm
Max. Machine Speed	170m /min	170m /min	170m /min
Max. Slitting and Rewinding Speed	150m /min	150m /min	150m /min
Tolerance of EPC	± 0.2mm	± 0.2mm	± 0.2mm
Motor Power	10Kw	11Kw	12Kw
Voltage	3.380.50HZ	3.380.50HZ	3.380.50HZ
Requirement of air pressure	5.5kg /cm 2 x0.5m 3 /min	5.5kg /cm 2 x0.5m 3 /min	5.5kg /cm 2 x0.5m 3 /min
Weight of Machine	2800 kg	3000 kg	3300kgs
Overall Dimension	3.3× 2.1× 1.55m	3.3× 2.3× 1.55m	3.3× 2.6× 1.55m
